Single Mode Test Light Source (XQ5110)
☆ Product Description:
OSCOM Test Light Source is kind of single mode high stability test light source that designed by OSCOM, it is use DFB laser as emission source. The light source is integrated with ATC, APC, RS232C technologies, and provided 1/2/3/4 channel bench or light source module. The representative wavelength is 1310nm、1490nm、1550nm、1625nm、1650nm ect. Besides, according to customer’s requirements, the light source can add a debiasing treatment to provide low polarization output. XQ5110 is stable and reliable, easy to use, it is suitable for optical components testing.
☆ Application Fields：
· Optical Fiber Communication Test · Optical Fiber Sensing Test
· Optical Fiber Device Production Test · Light Module Production Test
· Optical Fiber Communication System Integration · Construct Automatic Test System
☆ Technical Specifications：
Parameter \ Light Source
1310DFB
1490DFB
1550DFB
1625DFB
1650DFB
Photophore Device
DFB
Center Wavelength(nm)
±3
Spectral Width（nm）
±0.5 /(-20dB)
Output Light Power（dBm)
≥3
Fiber Type
SMF-28e
Output Attenuation
Step By Step Regulation/Continuous Adjustment
Short-term Stability
＜±0.005dB(15 minutes）
Long-term Stability
＜±0.03dB(8 hours）
Optical Fiber Connector
FC/PC、FC/UPC、FC/APC、ST/APC、SC/APC
Communication Interface
RS232C/USB（optional）
Operation Temperature(℃）
0～+40
Storage Temperature(℃）
-20～+70
Supply Power
AC 100～240V/50～60Hz/3A
Dimension (L´W´H)
330´225´93mm
☆ Ordering Information：
|
Product Type |
Photophore Type |
Appearance |
Operating Wavelength |
Output Power (dBm) |
Light Output Connector |
|
XQ5110 |
D=DFB-LD |
M-Module B-Benchtop |
1310nm 1490nm 1550nm 1625/1650nm |
00=0dBm 10=10dBm 13=13dBm |
FC/UPC FC/APC SC/APC ST/APC |
Example：XQ5110-D-B-1310-00-FC/APC
