(1+1)x1 or (2+1)x1 High Power Pump and Signal Combiners (PM or Non-PM)
High Transfer Efficiency
Stable and Reliable
☆ Application
High Power Fiber Laser
High Power Fiber Amplifier
☆ Features
High Transfer Efficiency
Stable and Reliable
☆ Application
High Power Fiber Laser
High Power Fiber Amplifier
☆ Specifications
|
Port Configuration |
（1+1）x1 or （2+1）x1 |
||
|
Pump Wavelength |
800~1000nm |
||
|
Signal Wavelength |
1030~1080nm or 1450~1600nm |
||
|
Signal Input Fiber |
X/125 |
X/125 |
X/125 or 20/400 |
|
Pump Fiber |
105/125 0.15NA/0.22NA |
X/125 0.15NA/0.22NA |
|
|
200/220 0.22NA |
|||
|
Output Fiber |
Y/125 |
Y/125 |
20/400 |
|
Pump Efficiency |
>90% |
>93% |
>95% |
|
Signal Insertion Loss |
<0.7db |
<0.7db |
<0.7db |
|
Total Power Handling |
200w |
300w |
500w |
|
Polarization ER |
>18db for PM type. |
||
|
Return Loss |
>45db |
||
|
Package Dimension |
Φ4x60mm，70x12x8mm，100x15x10mm，other |
||
|
Operating Temperature |
0℃~+75℃ |
||
|
Storage Temperature |
-40℃~+85℃ |
||
☆ Ordering Information
|
Device ID |
Explain |
Option |
|
XX-XXX |
Device type |
XQ-PCMB=PM XQ-PCMBC=Non PM |
|
X |
Port Configuration |
1=（1+1）x1，2=（2+1）x1 |
|
XXX |
Pump Wavelength |
Pump Wav：F=915nm，G=975nm Signal Wav：I=1064nm，O=1550nm，K=2000nm |
|
X |
Pumping direction |
F=forward pumping B=back-pumped |
|
X |
Pump Fiber |
A=105/125 NA:0.22 B=105/125 NA: 0.15 H=200/220 NA 0.22 |
|
X |
Signal Input Fiber |
1=DCF6/125 NA:0.14/0.46 2=DCF8/125 NA:0.14/0.46 3=DCF10/125 NA:0.08/0.46 4=DCF20/125 NA:0.08/0.46 5=DCF20/250 NA:0.08/0.46 6=DCF30/250 NA:0.06/0.46 8=DCF25/250 NA:0.06/0.46 |
|
X |
Output Fiber |
1=DCF6/125NA:0.14/0.4 2=DCF8/125NA:0.14/0.46 3=DCF10/125 NA:0.08/0.46 4=DCF20/125 NA:0.08/0.46 5=DCF20/250 NA:0.08/0.46 6=DCF30/250 NA:0.06/0.46 8=DCF25/250 NA:0.06/0.46 O=20/400 NA:0.06/0.46 |
|
XX |
Pigtail Length |
08=0.8m,10=1.0m |
|
X |
Package Dimension |
A=70x12x8mm B=100x15x10mm C=Φ4x60mm other |
Example：XQ-PCMB-1-F-A-1-1-08-A
