High Power Isolator

☆ Features

Low Insertion Loss

High Return Loss

High Isolation

High stability And Reliability

☆ Application

Polarization Maintaining Fiber Amplifier

Testing Instrument

Fiber Laser

  Features

Low Insertion Loss

High Return Loss

High Isolation

lHigh stability And Reliability



☆ Application

Polarization Maintaining Fiber Amplifier

Testing Instrument

Fiber Laser

☆ Specifications

Parameter

Unit

Value

Type



HPIIS

HPMIS

Center Wavelength

nm

980

1030,1064

980

1030,1064

Operating Wavelength Range

nm

±10

±5

±10

±5

Typ. Peak Isolation @ 23℃

dB

32~40

30

32~40

30

Min. Isolation @ 23℃

dB

25

Typ.Insertion Loss@23℃

dB

0.6

0.8

0.6

0.8

Max. Insertion Loss@23℃

dB

1.0

Max.Polarization Dependent Loss @ 23℃,Only For Pl

dB

0.15

Min.Extinction Ratio@23℃

Only For PM

Fast Axis Blocked

dB

-

22

Both Axis Working

dB

-

20

Min. Return Loss(Input To Output)

dB

50

45

50

45

Max.Average Optical Power

W

1, 2, 5 or Specify

20

1, 2, 5 or Specify

20

Max. Peak Power For ns Pulse

KW

-

10

-

10

Max. Tensile Load

N

5

Fiber Type

-

Hi 1060

PM Panda Fiber

Package Dimension

mm

72x34x33        55x28.5x28

Operating Temperature

+10 ~ +50

Storage Temperature

 0 ~ +60



 Ordering Information

Device ID

Explain

Option

XX

Device ID

XQ-HPMIS     XQ-HPIIS

XXXX

Center Wavelength

980=980nm    1064=1064nm

1040=1040nm  1030=1030nm

XX

Handling Power

01=1W         02=2W

05=5W         20=20W

X

Axis Alignment For PM

F=Slow axis working,Fast axis blocked

B=Both of axis working     N=No axis

X

Fiber Type

1=Hi1060 Fiber            S=Specified

2=PM Panda fiber

XXX

Pigtail Type

250=250μm Bare fiber

900=900μm Loose tube

XX

Fiber Length

08=0.8m        10=1m    S=Specify

X

Package Dimension

A=72x34x33mm            B=55x28.5x28mm

 ExampleXQ-HPMIS-980-01-F-2-250-08-A
